Autocad Mastering "Live"

Autocad Mastering "Live"

LE 2,500.00

Course Schedule(LIVE/ONLINE) Duration 24hrs.

19-27 FEB 2023 (20:00 to 23:00 Dubai [GMT +4]) 23-31 JUL 2023 (20:00 to 23:00 Dubai [GMT +4]) 10-18 Dec 2023 (20:00 to 23:00 Dubai [GMT +4])

Course Content

Draw Commands

(Line, Polyline, Rectangle, Polygon, Construction Line, Ray, Multiline, Hatch, Circle, Arc, Ellipse, Revision Cloud, Layers, Blocks, Text, Dimension, Print, Wipeout)

Modify Commands

(Erase, Move, Copy, Rotate, Mirror, Scale, Align, Stretch, Offset, Trim/ Extend, Fillet/ Chamfer, Array, Break, Explode, Join)

Utilities Commands

(Zoom, Grid Display, Dynamic Input, Ortho Mode, Polar Mode, Object snap, Properties, Inquiries)

HVAC Drawings

HVAC Design Plan
Ducts Distribution

Plumbing Drawings

Supply Plan
Drainage Plan
Site Drainage
